Sintered Filter Media Panels filter technology bases on pure surface filtration. It sustainably protects man and machine from harmful production emissions and enables absolutely sort- and contamination-free material recovery. This increases directly your productivity.
Lowest clean gas values, absolutely constant operating conditions, highest availability and energy efficiency are key features of the innovative technology. Sintered PE Surface filter elements show extreme durability and, depending on the process, long service life times of more than 15 years. Thereby the filters make a valueable contribution to environmental protection and sustainability.
Sintered PE Surface filter elements have proven themselves for decades in effective and safe particle separation in almost all areas of industry . Even with finest grain sizes, energy-efficient air recirculation is possible in most cases, proven even with toxic dust.
| Sinter plate filter | Advantages |
| Pure surface filtration due to PTFE embedded in the PE-matrix and non-flexible filter media | No penetration and deposition of dust particles in pores |
| Rigid body design | No wear and tear on the media due to movement (contraction during suction, expansion during cleaning) Long operational life time up to 10 years possible Low maintenance costs Filter elements can not fall down into the silo due to screwed mounting and no breaking of elements No tearing of element possible |
| Two screw mounting system and lower number of elements | Quick change of filter elements without the need for extra equipment (crane) |
| Perfectly suited for product recovery as medium is free of lints or fibres that could get loose | no danger of textile getting loose and contaminating the product |
Product Advantages:
High dust removal accuracy: Micro sized filter holes can remove 100% of dust particles above 1um, and can remove most of the dust particles above 0.1um.
Large filtration area: The corrugated design of the filtration area allows for 3-6 times the filtration area of the filter bag within the same volume.
Strong self-cleaning ability: The rigid structure allows the blowback gas to act more directly on the powder attached to the filter surface, without buffering, resulting in a thorough cleaning effect.
Clearing water and oil: The burning components of the filter element have a deeper performance in clearing water and oil.
Long service life: With high strength and toughness, it can withstand the repeated impact of high-pressure gas thousands of times a day, has super strong acid and alkali resistance, and perfect self-cleaning effect, with a service life of more than 10 years.
Constant pressure: The plastic fired board matrix will not experience blockage.
| Model | L (mm) | W (mm) | D (mm) | Filter Area (m2) | Weight (kg) |
| Delta2 500 | 533 | 564 | 80 | 1.57 | 4.8 |
| Delta2 750 | 767 | 564 | 80 | 2.34 | 6.3 |
| Delta2 1000 | 1023 | 564 | 80 | 3.18 | 7.9 |
| Delta2 1500 | 1504 | 564 | 80 | 4.75 | 10.9 |
| Steel Industry | Nonferrous Metallurgy | Automobile Industry | Ore Processing | Rubber Tyre Industry |
| Electronics Industry | Foundry | Laser-Cutting | Chemical Industry | Pharmacy |
| Food Processing | Glass and Ceramics Industry | Cement and Lime Industry | Metal Work | … |
